Straight/Rigid
Box contains 10 forms, each 12 foot in length for a total of 120 lineal feet. Hardware is not included.
- Superior to lumber
- Stackable
- Washable & reusable
Back Poly Meta Forms®
Features
Rigidity of Lumber
*Aluminum tube inserts reinforce the entire length of the form.
Size
- 4" and 6" Heights
- All 12' Lengths
- Uniform Sizes and Lengths compared to lumber
End Connection
- Tight Secure Form Joint
- Fast, Accurate Alignment
- Eliminates Toe-Nailing
Form Specifications:
Material:
High Density Polyethylene (HDPE). One time purchase, documented reuses of 150x or more.
*Aluminum tube inserts reinforce the entire length of the form.
Size:
- 2"x 4"x 12' - size guaranteed
- 2"x 6" x 12'- size guaranteed
- All 12’ lengths
- Uniform Sizes and lengths compared to lumber
Weight and Packaging:
10 Forms per Box
- 4" Straight = 1.0 lbs. per foot/ 129 lbs. per box/ #869-450
- 6" Straight= 1.25 lbs. per foot/ 155 lbs. per box/ #869-650
stake pocket specifications:
Metal stake pockets are interchangeable in both 4" and 6" forms
The "Twist" pocket provides multiple staking options since it can be easily inserted at any location along the length of any form. Recommended three twist pockets per length of any 4" or 6" form. (one bucket per box of forms).
The "Slide” pocket is inserted at the end of either the 4" or 6" poly form. Convenient connection to wood with predrilled nail holes. Recommended one slide pocket per form (one bucket per box of forms).
Material:
Special Analysis Steel
Size:
- Slide: 1.3 lbs. per pocket/ 23 lbs. per bucket/ part #869-025
- Twist: 1.3 lbs. per pocket/ 42 lbs. per bucket/ part #869-040
- Stacking: 3.0 lbs. per pocket/ 17 lbs. per bucket
Weight and Packaging:
- 30 Twist pockets per bucket
- 15 Slide pockets per bucket
